ZTA series
High performance high capacity type digital force gauge has capacity of 5000N and is the higher-end model with added functions to ZTS such as input/output of displacement and continuous data saving to USB. Next series digital force gauge with firmware Ver.5 or later offers improved measurement stability with less noise,
Model |
ZTA |
Feature |
Standard Model with high functionality and usability. |
Accuracy |
+/-0.2%F.S.+/-1digit |
Measurement Unit |
N, kgf, lbf |
Display |
4-digit Organic EL |
Display update |
16 / sec |
Sampling Rate |
2000 data / sec at maximum |
Battery |
6.5 hours (2 hours for re-charging) |
Safe overload rating |
Approx.200%F.S |
Operating environment |
Temperature: 0 to +40 degree Celsius, Humidity: 20 to 80%RH |
Function |
Customized display (header and footer), Peak hold (tension and compression), Internal 1000 points data memory, Comparator (judgment of OK or NG), Reversible display, Sign inversion, Zero clear timer, +NG alarm, Off timer (auto power off), Dumping, Time display, 1st/2nd peak, Displacement detection at force peak value, Displacement zero reset at selected force, Setting lock |
Output |
USB, RS232C / ±2VDC analog output (D/A), Comparator 3 steps (-NG/OK/+NG), Overload alarm |
Overload warning |
Approx.110%F.S. (Warning message and alarm) |
External connecting switch |
Power ON / OFF / Send and Hold / Zero reset / Peak and Real-time switching |
Available linear scales |
- Online driver output (a line receiver according to RS422/485 must be built in.) - Open collector output (Voltage drop between contacts must be smaller than 0.5V.) |
Weight |
From 2N to 1000N Model: Approx.490g (*5) 2500N, 5000N: Approx.1100g |
Dimensions |
Please refer to dimensions |
Accessory |
AC adapter, Inspection certificate, CD driver (including data logging software), Attachments (The set of attachments varies according to range.), Handles (only for 2500N/5000N range), USB cable, Carrying case, Adaptor for USB flash drive |
