Multi Protocol Analyzer
LE-8600X/LE-8600XR
Multi Protocol Analyzer LE-8600X LE-8600XR :
While high-speed networks using optical fiber cables are becoming more widespread in high-speed servers in data centers and base stations, process management servers in factories, etc., the demand for a network communication analyzer that is easy to use even in the on-site test is growing - The analyzer should be able to execute independently 10GbE LAN measurement, load testing, and failure analysis and be used at customer sites.
The LE-8600X/LE-8600XR are equipped with two measurement ports compatible with SFP/SFP+ modules and are handy type Ethernet LAN analyzer that supports high-speed LAN measurement tests that use single-mode or multi-mode optical fiber cables as a single unit.
The model is equipped with a 7-inch wide-color LCD with a touch panel, thus you can check the measurement data immediately on-site without using a personal computer. You can log the data to the 1GB capture memory and a built-in 500GB SSD.
In addition, as the time stamps that are time-corrected with high accuracy by GNSS signals can be added to the monitor data, by checking the time stamps you can compare and analyze the data measured simultaneously at two points for a long period of time to investigate a communication failure.
Furthermore, by replacing the standard measurement board with another measurement board (sold separately), the communication interface to be measured can be expanded later, so it can be widely used from network systems to development testing and maintenance of embedded communication equipment.
| Interface | SFP+ 2ports. A and B (optional SFP/SFP+ modules to be connected） 10GBASE-T/SR/LR/ER, 1000BASE-T/SX/LX/EX etc. |
|---|---|
| With SB-GE2 | 10/100/1000BASE-T |
| With SB-R2TS1 | RS-232C, RS-530, RS-422/485, TTL |
| Memory/Internal Storage | Capacity: 1Gbyte (96byte to 12320byte for 1 frame） Internal storage: 500GB |
| SFP Module Information Display | Displays detailed information of the SFP/SFP+ module inserted to the measurement port |
| Online Monitor Function | Recording and real-time display of Ethernet frames flowing between SFP+ ports A and B |
| Capture Performance | 10Gbps |
| Frame Size | 60byte to 9Kbyte |
| Time Stamp | The reception time is added as timestamp data for each received frame. Resolution: 8n seconds / 1u seconds / 10u seconds can be selected |
| Data Display/Control | Scroll display, 2-split comparison display, jump operation to specified screen, mark jump operation |
| Translation | Supported protocols: IPv4, IPv6, ARP, ICMP, TCP, UDP, DHCP, EtherCAT |
| PcapNG Conversion | Measurement data can be converted and saved to a PcapNG format file |
| Filter Function | Can monitor only the specific frames that match one or two specified conditions. |
| Trigger Function | Condition: When the specified frame is received or when the external TTL signal changes. Action: Automatically stop the monitor, count the number of matching conditions, output an external TTL signal |
| Search Function | From the measured data, it can search, cue, and count only the specific frames that match the specified conditions. |
| Statistical Analysis Function | Statistics of two frame counter values can be collected and displayed in a graph at specified intervals (2 seconds to 240 minutes), and all frame counter values and data rate can be displayed in real time. |
| PG Function | From the SFP+ port A and B it can output arbitrary packet set in 16 transmission data tables (total 32k data) of each port at arbitrary wire rate |
| Ping Function | Can issue a PING command from SFP+ port A to display the number of responses and response time (current value, maximum value, minimum value, average value). |
| Port Blink Function | The connection destination of the cable can be confirmed by periodically blinking the link LED of the hub port to which the cable of SFP+ port A is connected. |
| Auto Save Function | The contents of the capture memory (monitored data) can be automatically saved as a communication log file to the built-in SSD or to a storage device such as USB memory / SDHC card. |
| Auto Save Mode | Re-recording mode, append mode, Max stop (records up to specified capacity and stop) mode can be selected |
| Additional Functions | Time synchronization function by PPS signal of GNSS or external PPS signal, auto backup function, time specified automatic RUN/STOP function, power-on automatic RUN function |
| Display | 7 inch TFT color LCD with capacitive touch panel |
| Line Status LED | 11 LEDs always display the connection status of SFP+ port A and B |
| LAN Port | RJ45 connector, 1000BASE-T Ethernet: IEEE 802.3 for PC connection |
| USB Device Port | Type-C connector, SuperSpeed transfer supported. For PC connection |
| USB Host Port | Standard A connector, SuperSpeed transfer supported. For external storage (USB memory/SSD) |
| SD Card Slot | For standard size SD / SDHC memory cards, compliant with SD Association standard |
| External I/O Terminal | 4-pin connector for TTL level trigger input/output signals |
| GPS Antenna Connector | SMA (female) connector for active GPS antenna connection |
| PPS Signal Connector | SMA (female) connector for TTL level PPS I/O signals |
| Wi-Fi Connection | IEEE802.11b/g/n frequency range: 2412MHz to 2484MHz Transmission power 802.11b: +18.5dBm, 802.11g: +18.0dBm, 802.11n: +17.0dBm |
| Power | Attached AC adapter or lithium-ion secondary battery (model number: P-26LW2) Battery drive time: 2 hours |
| Ambient Temperatures | In operation : 0 to 40 degree Celsius, In storage : -20 to 50 degree Celsius |
| Ambient Humidity | 20 to 85%RH (No condensation) |
| Standard | CE (Class A) |
| Size & Weight | 234(W) x 186(D) x 44(H)mm, about 990g |
| Accessories | LAN cable 1pc, USB cable (standard A-Type-C), external signal input/output cable (LE-4TG), AC adapter (6A-181WP09), carrying back (LEB-01), utility CD, quick start guide, warranty card |
